HEL Performance Clutch Line for Tremec T56 Transmission using an OEM-style LS7 Slave Cylinder Flexible Clutch Feed Line and Remote Bleed Line HEL Stainless Steel Braided


Color: Black
Price:
Sale price$134.74

Description

Tremec T56 clutch feed and bleed lines. Both are fully fire-sleeved with stainless steel fittings, bleed nipple and stainless braided hose. For ease of installation, the feed has a AN3 female swivel fitting to attach the remainder of your clutch line. The use of a remote bleed line eases clutch servicing due to greatly improved access and visibility.

For use with OEM-style LS7 slave cylinders (as in photos). Clutch feed line input is 3/8" x 24 UNF (AN3).

We offer an optional quick release dry break fitting to speed up dropping/installing the box in time sensitive situations, eliminating the need for re-bleeding. If you choose this option, you will need to spec up a custom line to come from the dry break.

SLAVE CYLINDER NOT INCLUDED.



Want to see behind the scenes?

Take a look at the unique manufacturing and assembly process behind our flagship braided brake hoses.

Hose Specifications
Internal Material (Core) PTFE
Internal Material (Overbraid) Stainless Steel - 303/304
External Material (Outer) PVC (Clear/Color)
Fitting Material (Hose End) Stainless Steel - 303/304
Internal Diameter 3.5mm (0.13")
External Diameter 7.5mm (0.29")
Minimum Bend Radius 38.0mm (1.49")
Minimum Temperature -70°C / -94°F
Maximum Temperature 260°C / 500°F
Maximum Operating Pressure 290 BAR / 4,206 PSI
Burst Pressure 870 BAR / 12,618 PSI
Finish Clear/Colored PVC
Brand HEL Performance
